– H.265+, H.265, H.264+, H.264, and MPEG-4 encoding
– Full-channel recording at up to 8MP/4K
– Plug and play with up to four independent PoE cameras
– HDMI and VGA output ports
– Up to 4K UHD (3840 x 2160) output resolution
– Four-channel synchronous playback
– Supported analytics include Smart Search, Smart Playback, basic line crossing, and intrusion detection
– 2 x USB 2.0 ports
– CSA, FCC, CE, and cUL certified
| Channels | 8 |
| Resolution | Up to 8 MP |
Network
| Input Bandwidth | 80 Mb/s |
| Output Bandwidth | 80 Mb/s |
| Network Protocols | TCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, and UPnP |
Video Output
| Recording Resolutions | 8MP, 4 MP, 3 MP, 1080p, UXGA, 720p, VGA, 4CIF, DCIF, 2CIF, CIF, and QCIF |
| HDMI/VGA Output | 1 channel |
| Output Resolutions | 4K UHD (3840 x 2160) at 30 Hz; 1920 x 1080, 1600 x 1200, 1280 x 1024, 1280 x 720, 1024 x 768 at 60 Hz |
Decoding and Playback
| Decoding Formats | H.265+, H.265, H.264+, H.264, MPEG-4 |
| Live View / Playback | 8MP, 4 MP, 3 MP, 1080p, UXGA, 720p, VGA, 4CIF, DCIF, 2CIF, CIF, and QCIF |
| Synchronous Playback | 8 channels |
| Capability | 1 Channel at 8 MP; 4 channels at 1080p |
Hard Disk
| SATA | 1 x SATA interface |
| Capacity | Up to 6 TB 2 TB preinstalled |
External Interface
| Network Interface | 1 x RJ45, 10M/100M self-adaptive Ethernet port |
| USB Interface | 2 x USB 2.0 |
PoE
| PoE Interface | 8-port RJ45 10/100 Mb/s self-adaptive Ethernet interface |
| Power | ≤75 W |
| PoE Standard | IEEE 802.3af/at |
General
| Power Supply | 48 VDC |
| Power | ≤90 W |
| Power Consumption | Without HDDs: ≤10 W |
| Operating Temperature | 14 to 131°F / -10 to 55°C |
| Operating Humidity | 10 to 90% |
| Rack Height | 1 RU |
| Dimensions | 10.2 x 8.9 x 1.9″ / 260 x 225 x 48 cm |
| Weight | 2.2 lb / 1 kg, without HDD |
Packaging Info
| Package Weight | 5.2 lb |
| Box Dimensions (LxWxH) | 16 x 11 x 4″ |
